供應美(mei)國ADVANTAGE CONTROLLERS泵、閥
Includes a 1 X 16 backlit LCD, on/off & stroke indicator LED, keypad and dust cover
A145X1-KFCV 75 PSI 45 GPD / 7 07 LPH @ 75 PSI / 5 1 bar
A130X1-KFCV 110 PSI 30 GPD / 4 73 LPH @ 110 PSI / 7 5 bar
A115X1-KFCV 150 PSI 15 GPD / 2 36 LPH @ 150 PSI / 10 3 bar
A217X1-KFC2 250 PSI 17 GPD / 2 68 LPH @ 250 PSI / 17 2 bar
Series B
Series B pumps come standard with a rotary encoder switch to allow exact stroke speed
setting of pumps, on/off indicator light, stroke indicator light and panel dust cover
B145X1-KFCV 75 PSI 45 GPD / 7 07 LPH @ 75 PSI / 5 1 bar
B130X1-KFCV 110 PSI 30 GPD / 4 73 LPH @ 110 PSI / 7 5 bar
B115X1-KFCV 150 PSI 15 GPD / 2 36 LPH @ 150 PSI / 10 3 bar
B217X1-KFC2 250 PSI 17 GPD / 2 68 LPH @ 250 PSI / 17 2 bar
Series C
Series C pumps feature adjustable stroke length with fixed speed, 10:1 turndown
PSI 110 110 110 110 110 250 250 250 250 250
GPD 30 20 15 10 5 17 15 10 5 2
MODEL C130 C120 C115 C110 C105 C217 C215 C210 C205 C202R00267 PE 1/4” ( 25) OD / 1/8” ( 125) ID
R00122 PE 3/8” ( 375) OD / 1/4” ( 25) ID
R00151 PE Blk UV resist 3/8” ( 375) OD / 1/4” ( 25) ID
R00167 PE Blk UV resist 1/4” ( 25) OD / 1/8” ( 125) ID
R00255 Clear Vinyl 3/8” ( 375) OD / 1/4” ( 25) ID
R00268 PVDF 3/8” ( 375) OD / 1/4” ( 25) ID
100’ Roll (add -100 suffix to part # for 100’ roll)
-100 300 PSI / 20 6 Bar @ 73°F (22°C)
-100 400 PSI / 27 5 Bar @ 73°F (22°C)
-100 200 PSI / 13 7 Bar @ 73°F (22°C)
-100 200 PSI / 13 7 Bar @ 73°F (22°C)
-100 300 PSI / 20 6 Bar @ 73°F (22°C)
-100 Suction / Prime only
N/A 250 PSI / 17 2 Bar @ 73°F (22°C)
Additional Parts
R00125 Head, Kynar large (30 & 45 GPD)
R00126 Head, Kynar small (15 & 17 GPD)
R00006 Diaphragm, small (15 & 17 GPD)
R00007 Diaphragm, large (30 & 45 GPD)
R00068 Ring, support small diaphragm
R00069 Ring, support large diaphragm
R00129 Tubing nut Kynar
R00108K 1/4 tubing adaptor Kynar
A145X1-KFCV 75 PSI 45 GPD / 7 07 LPH @ 75 PSI / 5 1 bar
A130X1-KFCV 110 PSI 30 GPD / 4 73 LPH @ 110 PSI / 7 5 bar
A115X1-KFCV 150 PSI 15 GPD / 2 36 LPH @ 150 PSI / 10 3 bar
A217X1-KFC2 250 PSI 17 GPD / 2 68 LPH @ 250 PSI / 17 2 bar
Series B
Series B pumps come standard with a rotary encoder switch to allow exact stroke speed
setting of pumps, on/off indicator light, stroke indicator light and panel dust cover
B145X1-KFCV 75 PSI 45 GPD / 7 07 LPH @ 75 PSI / 5 1 bar
B130X1-KFCV 110 PSI 30 GPD / 4 73 LPH @ 110 PSI / 7 5 bar
B115X1-KFCV 150 PSI 15 GPD / 2 36 LPH @ 150 PSI / 10 3 bar
B217X1-KFC2 250 PSI 17 GPD / 2 68 LPH @ 250 PSI / 17 2 bar
Series C
Series C pumps feature adjustable stroke length with fixed speed, 10:1 turndown
PSI 110 110 110 110 110 250 250 250 250 250
GPD 30 20 15 10 5 17 15 10 5 2
MODEL C130 C120 C115 C110 C105 C217 C215 C210 C205 C202R00267 PE 1/4” ( 25) OD / 1/8” ( 125) ID
R00122 PE 3/8” ( 375) OD / 1/4” ( 25) ID
R00151 PE Blk UV resist 3/8” ( 375) OD / 1/4” ( 25) ID
R00167 PE Blk UV resist 1/4” ( 25) OD / 1/8” ( 125) ID
R00255 Clear Vinyl 3/8” ( 375) OD / 1/4” ( 25) ID
R00268 PVDF 3/8” ( 375) OD / 1/4” ( 25) ID
100’ Roll (add -100 suffix to part # for 100’ roll)
-100 300 PSI / 20 6 Bar @ 73°F (22°C)
-100 400 PSI / 27 5 Bar @ 73°F (22°C)
-100 200 PSI / 13 7 Bar @ 73°F (22°C)
-100 200 PSI / 13 7 Bar @ 73°F (22°C)
-100 300 PSI / 20 6 Bar @ 73°F (22°C)
-100 Suction / Prime only
N/A 250 PSI / 17 2 Bar @ 73°F (22°C)
Additional Parts
R00125 Head, Kynar large (30 & 45 GPD)
R00126 Head, Kynar small (15 & 17 GPD)
R00006 Diaphragm, small (15 & 17 GPD)
R00007 Diaphragm, large (30 & 45 GPD)
R00068 Ring, support small diaphragm
R00069 Ring, support large diaphragm
R00129 Tubing nut Kynar
R00108K 1/4 tubing adaptor Kynar
