寶(bao)德(de)BURKERT電磁閥類型說明

0330閥(fa)門(men)是(shi)一種直(zhi)接(jie)作(zuo)(zuo)用，介質分離(li)的(de)樞軸式電(dian)樞閥(fa)。它有(you)3/2和2/2版本(ben)(ben)。作(zuo)(zuo)為(wei)3/2版本(ben)(ben)，它可(ke)(ke)以用作(zuo)(zuo)分配器或混合(he)(he)閥(fa)。根據應(ying)用，可(ke)(ke)以使用各種隔膜材(cai)料組合(he)(he)和操作(zuo)(zuo)方法。標準(zhun)黃銅外殼(ke)(ke)滿足所(suo)有(you)歐洲飲用水(shui)要求(qiu)。不銹(xiu)鋼(gang)（316L），PVDF和聚丙(bing)烯外殼(ke)(ke)版本(ben)(ben)*善了產(chan)品。電(dian)磁線圈采用耐(nai)化學腐蝕的(de)環(huan)氧樹(shu)脂模制而(er)成(cheng)。 0330配有(you)手動控制裝置(zhi)，用于(yu)調試和測試。為(wei)了降低(di)能量需求(qiu)，所(suo)有(you)線圈都可(ke)(ke)以通過電(dian)子(zi)功率降低(di)或作(zuo)(zuo)為(wei)脈(mo)沖版本(ben)(ben)來提(ti)供。可(ke)(ke)以用位置(zhi)反饋將(jiang)開關(guan)狀態指示(shi)為(wei)二進制或NAMUR信號。與符合(he)(he)DIN EN 17301-803 A型的(de)插(cha)頭組合(he)(he)使用時，閥(fa)門(men)符合(he)(he)防(fang)護等級IP65 / 67  - 與不銹(xiu)鋼(gang)或塑料外殼(ke)(ke)NEMA 4X組合(he)(he)使用。

直動式介質(zhi)分離(li)閥，直徑大DN 5

免維護(hu)的(de)樞軸電樞技(ji)術

防(fang)振，塊螺紋線圈系統(tong)

適(shi)用于(yu)腐蝕性(xing)堿性(xing)和酸性(xing)溶液

服務友(you)好，強(qiang)大的手(shou)動(dong)操作

如需選(xuan)擇(ze)正確的(de)產(chan)品，請參閱技術數(shu)據(ju)，圖像和(he)注(zhu)釋(shi)，以便(bian)根據(ju)數(shu)據(ju)表正確使用。

BURKERT電磁閥(fa)00136350上海區域(yu)授權(quan)***

Type Description

The 0330 valve is a direct-acting, media separated pivoted armature valve. It is available in 3/2- and 2/2-way versions. As a 3/2-way version, it can be used as a distributor or mixing valve. Various diaphragm material combinations and methods of operation are available depending on the application. The standard brass housing satisfies all European drinking water requirements. Stainless steel (316L), PVDF, and polypropylene housing versions complete the offering. The solenoid coils are moulded with a chemically resistant epoxy. The 0330 is equipped with manual override for commissioning and testing. For reduced energy requirements all coils can be delivered with electronic power reduction or as an impulse version. The switching status can be indicated with position feedback as a binary or NAMUR signal. In combination with a plug in accordance with DIN EN 17301-803 Form A, the valves satisfy protection class IP65/67 – in combination with a stainless steel or plastic housing NEMA 4X.

• Direct-acting, media separated valve with diameter of up to DN 5
• Maintenance-free pivoted armature technology
• Vibration-proof, block screwed coil system
• Suitable for aggressive alkaline and acidic solutions
• Service-friendly, robust manual operation
